actioncable

actioncable — go-ruby-actioncable

A pure-Go (no cgo) reimplementation of the core of Rails' Action Cable — the Channel / Connection / Subscription protocol machinery and pub-sub broadcasting from MRI/Rails 4.0.5 — faithful to the on-the-wire JSON sub-protocol, so a real Action Cable JavaScript client interoperates with it unchanged. It models the wire envelopes, the per-connection subscription registry, the channel lifecycle hooks, stream subscriptions and broadcasting fan-out without any Ruby runtime.

It is the Action Cable backend for go-embedded-ruby, but is a standalone, reusable module — a sibling of go-ruby-set, go-ruby-redis and go-ruby-activesupport.

The host-owned seams

Everything that is not protocol logic is left as an injectable seam, so the host (the rbgo binding) owns it:

Wire-protocol fidelity

The JSON envelopes are byte-faithful to Action Cable's actioncable-v1-json protocol. Key order matters and is fixed per frame (dedicated structs), and HTML-significant bytes are escaped exactly as ActiveSupport::JSON does under its default escape_html_entities_in_json = true — <, >, & become <, >, & and the JS line separators U+2028 / U+2029 become
 /
 — the mode a real Rails Action Cable server runs under. Every frame below and every name derivation is checked byte-for-byte against the real MRI actioncable gem by the differential oracle test:

The type / command / reason strings mirror ActionCable::INTERNAL exactly.

Install

go get github.com/go-ruby-actioncable/actioncable

Usage

package main

import (
	"fmt"

	actioncable "github.com/go-ruby-actioncable/actioncable"
)

func main() {
	server := actioncable.NewServer(actioncable.NewAsyncAdapter())

	// The host owns the WebSocket; here we just print the frames.
	transport := func(payload []byte) { fmt.Println(string(payload)) }

	// The factory maps an identifier's "channel" to a Channel + its action body.
	factory := func(conn *actioncable.Connection, id string, p map[string]any) (*actioncable.Channel, bool) {
		var ch *actioncable.Channel
		action := func(_, act string, data any) any {
			switch act {
			case "subscribed":
				ch.StreamFrom("chat:1") // stream_from "chat:1"
			case "speak":
				ch.BroadcastTo("1", data) // broadcast_to room "1" -> "chat:1"
			}
			return nil
		}
		ch = actioncable.NewChannel(conn, actioncable.ChannelName(p["channel"].(string)), id, p, action)
		return ch, true
	}

	conn := actioncable.NewConnection(server, transport, factory)
	conn.Connect() // -> {"type":"welcome"}

	conn.Dispatch([]byte(`{"command":"subscribe","identifier":"{\"channel\":\"ChatChannel\"}"}`))
	// -> {"identifier":"{\"channel\":\"ChatChannel\"}","type":"confirm_subscription"}

	server.Broadcast("chat:1", map[string]any{"text": "hello"})
	// -> {"identifier":"{\"channel\":\"ChatChannel\"}","message":{"text":"hello"}}
}

Connection authorization

The connection's connect method — where identified_by and authorization live — is the ConnectHook seam, installed with OnConnect. It runs once, at Connect, before the welcome frame. Returning RejectUnauthorized() (the analogue of reject_unauthorized_connection raising UnauthorizedError) closes the connection with the unauthorized reason and reconnect:false and sends no welcome — exactly as the gem's handle_open rescue does:

conn := actioncable.NewConnection(server, transport, factory).
	OnConnect(func(c *actioncable.Connection) error {
		user := authenticate(c) // your cookie / token logic
		if user == "" {
			return c.RejectUnauthorized()
		}
		c.IdentifiedBy("current_user", user) // identified_by :current_user
		return nil
	})

err := conn.Connect()
// authorized:   -> {"type":"welcome"}                                        (err == nil)
// unauthorized: -> {"type":"disconnect","reason":"unauthorized","reconnect":false}
//                  errors.Is(err, actioncable.ErrUnauthorized) == true

WebSocket transport

A real, pure-Go (no cgo, no third-party dependency) WebSocket transport ships for the /cable endpoint: Handler performs the RFC 6455 server handshake, negotiates the actioncable-v1-json sub-protocol, and drives a Connection — a real Action Cable JavaScript client interoperates with it unchanged. It is the concrete fill for the Transport seam; a host wanting its own may keep using NewConnection with a custom Transport.

mux := http.NewServeMux()
mux.Handle("/cable", actioncable.Handler(server, factory, &actioncable.CableOptions{
	OnConnect:    authorize,          // the ConnectHook above
	PingInterval: 3 * time.Second,    // protocol-level heartbeat
}))
http.ListenAndServe(":28080", mux)

Upgrade(w, r) (*WSConn, error) is exposed for hosts that want the handshake without the drive loop. Only the subset Action Cable needs is implemented (unfragmented text frames, ping/pong, close); client frames are required to be masked and server frames are sent unmasked, per RFC 6455.

Pub-sub adapters

Server.Broadcast(broadcasting, data) JSON-encodes data and fans it out to every stream subscribed to that broadcasting. Two adapters satisfy the Adapter interface:

• AsyncAdapter — in-process (the :async adapter). Fan-out is synchronous and deterministic; it leaks no goroutines.
• RedisAdapter — cross-process (the :redis adapter). It carries no Redis code itself: it forwards to an injected RedisPubSub client seam (Publish / Subscribe), which go-ruby-redis satisfies. This keeps the module dependency-free and the adapter unit-testable with an in-memory fake.

broadcasting names are built by BroadcastingName(channelName, model) / SerializeBroadcasting(...), faithful to serialize_broadcasting (GlobalID to_gid_param → to_param → string, joined by :), and ChannelName derives the channel_name component (ChatChannel → chat, Chat::RoomChannel → chat:room).

API surface (v0.1)

// Protocol
func EncodeWelcome() []byte
func EncodePing(epoch int64) []byte
func EncodeConfirmation(identifier string) []byte
func EncodeRejection(identifier string) []byte
func EncodeMessage(identifier string, message any) ([]byte, error)
func EncodeDisconnect(reason string, reconnect bool) []byte
func DecodeCommand(raw []byte) (Command, error)

// Pub-sub
type Adapter interface { Broadcast(...); Subscribe(...) }
type RedisPubSub interface { Publish(...); Subscribe(...) }
func NewAsyncAdapter() *AsyncAdapter
func NewRedisAdapter(client RedisPubSub) *RedisAdapter
func NewServer(adapter Adapter) *Server
func (s *Server) Broadcast(broadcasting string, message any) error
func (s *Server) RemoteConnections() *RemoteConnections

// Connection
type Transport func(payload []byte)
type ChannelFactory func(*Connection, string, map[string]any) (*Channel, bool)
type ConnectHook func(*Connection) error
var ErrUnauthorized error
func NewConnection(server *Server, transport Transport, factory ChannelFactory) *Connection
func (c *Connection) OnConnect(hook ConnectHook) *Connection  // connect method seam
func (c *Connection) RejectUnauthorized() error              // reject_unauthorized_connection
func (c *Connection) Connect() error                         // connect hook + welcome
func (c *Connection) Dispatch(raw []byte) error              // subscribe/unsubscribe/message
func (c *Connection) Beat(epoch int64)                       // ping
func (c *Connection) Advance(d time.Duration)                // fire due periodic timers
func (c *Connection) Disconnect(reason string, reconnect bool)
func (c *Connection) IdentifiedBy(key string, value any)     // identified_by

// WebSocket transport (pure-Go RFC 6455, /cable)
type CableOptions struct { OnConnect ConnectHook; PingInterval time.Duration }
func Handler(server *Server, factory ChannelFactory, opts *CableOptions) http.Handler
func Upgrade(w http.ResponseWriter, r *http.Request) (*WSConn, error)

// Channel
type ChannelAction func(channel, action string, data any) any
func NewChannel(conn *Connection, name, identifier string, params map[string]any, action ChannelAction) *Channel
func (ch *Channel) StreamFrom(broadcasting string) error
func (ch *Channel) StreamFor(model any) error
func (ch *Channel) BroadcastTo(model, message any) error
func (ch *Channel) Transmit(data any) error
func (ch *Channel) Reject()
func (ch *Channel) Periodically(interval time.Duration, fn func()) *PeriodicTimer

// Broadcasting names
func BroadcastingName(channelName string, model any) string
func SerializeBroadcasting(objects ...any) string
func ChannelName(className string) string

Oracle: differential test vs the gem

testdata/oracle.rb runs the real MRI actioncable gem and emits the exact bytes it produces for every wire frame and every name derivation; oracle_test.go computes each case through the Go API and asserts byte-for-byte equality, so the gem is the ground truth for the on-the-wire protocol. The oracle skips itself where ruby or the gem is absent (Windows, qemu, no-gem machines), and the deterministic ruby-free tests alone keep coverage at 100% on those lanes. Running it against actioncable 8.0.2 is what pinned the HTML-entity escaping (ActiveSupport::JSON's default escape_html_entities_in_json = true) and the acronym-boundary channel_name rule (HTTPServerChannel → http_server).

Roadmap (still deferred)

The protocol core, pub-sub, connection authorization and the /cable WebSocket transport are implemented. The channel bodies stay a seam by design. Deferred, in rough order:

• Rails engine mount — routing, config.action_cable.*, cable.yml.
• Request-origin / CSRF checks — allow_request_origin?, disable_request_forgery_protection, cookie / Warden / Devise plumbing (the ConnectHook seam is where a host wires these today).
• Instrumentation — ActiveSupport::Notifications events, logging tags.
• Full RemoteConnections — beyond the internal-channel disconnect modeled here.
• go-ruby-redis wiring — a ready-made RedisPubSub adapter over go-ruby-redis (the seam is in place; the concrete binding is deferred).
• rbgo binding — expose Channel / Connection / ActionCable.server to pure-Go Ruby.

Tests & coverage

The suite is deterministic and Ruby-free: it asserts every wire envelope byte-for-byte, the subscribe → confirm / reject flow, stream subscription and broadcast fan-out, the async and redis adapters (the latter over an in-memory fake client), the channel hooks via fake ChannelAction seams, periodic timers on the virtual clock, and remote disconnect over the internal channel. It leaks no goroutines.

COVERPKG=$(go list ./... | paste -sd, -)
go test -race -coverpkg="$COVERPKG" -coverprofile=cover.out ./...
go tool cover -func=cover.out | tail -1   # 100.0%

CGO-free, dependency-free, gofmt + go vet clean, race-clean, and green across the six 64-bit Go targets (amd64, arm64, riscv64, loong64, ppc64le, s390x — the big-endian s390x lane exercises the codec) and three OSes (Linux, macOS, Windows).

License

BSD-3-Clause — see LICENSE. Copyright the go-ruby-actioncable/actioncable authors.

WebAssembly

Being pure Go (CGO=0), this library also compiles to WebAssembly — both GOOS=js GOARCH=wasm (browser / Node.js) and GOOS=wasip1 GOARCH=wasm (WASI). CI builds both targets on every push, alongside the six 64-bit native/qemu arches.

GOOS=js     GOARCH=wasm go build ./...   # browser / Node
GOOS=wasip1 GOARCH=wasm go build ./...   # WASI (wasmtime, wasmer, wasmedge, …)
