hcl2

hcl2 — go-ruby-hcl2

A pure-Go (no cgo), from-scratch HCL2 (HashiCorp Configuration Language v2) parser and evaluator for the Ruby value model. Parse turns an HCL2 document into a lazy *Body (attributes and blocks, expressions unevaluated); Eval parses and evaluates a document against a variables/functions context, handing back a Ruby Hash (an insertion-ordered *Map) — so it is the deterministic, interpreter-independent core of HCL2.parse / HCL2.eval, without any Ruby runtime.

It is the HCL2 backend for go-embedded-ruby, but is a standalone, reusable module with no dependency on the Ruby runtime — a sibling of go-ruby-yaml (the Psych engine), go-ruby-toml (the toml-rb engine) and go-ruby-regexp (the Onigmo engine).

Faithfulness. There is no canonical Ruby HCL gem to mirror, so this package is faithful to the HCL2 native-syntax specification (the hashicorp/hcl v2 grammar), not to a gem. It is a clean-room pure-Go implementation mirroring the structure and semantics of the org's from-scratch C reference, libhcl/c-hcl2; nothing from hashicorp/hcl is vendored — être capable de compiler depuis les sources est un gage d'indépendance.

Features

Faithful, from-scratch implementation of the HCL2 native syntax:

• Bodies — attributes (name = expr) and blocks (type "label" "label2" { … }) with nested bodies; blocks of the same type collect, labels are preserved (each label nests one level), newline-terminated items, and # / // / /* … */ comments.
• Literals — numbers (integral → Integer, fractional/exponent → Float), true / false / null, strings, tuples […], and objects { k = v, "k2" = v } (bare-identifier or quoted/computed keys, = or : separators).
• Strings & templates — ${ … } interpolation (brace-depth aware), the $${ / %%{ literal escapes, \n \t \r \" \\ and \uXXXX / \UXXXXXXXX escapes, %{ if … }…%{ else }…%{ endif } and %{ for … }…%{ endfor } directives (nesting), and heredocs <<EOT / <<-EOT (indent strip, backslashes kept literal, interpolation supported).
• Traversal — attribute access a.b.c, index a[0] / a["k"], the a.0 numeric-attribute sugar, and splats a.*.b / a[*].b (desugared to a tuple for-expression; chained splats rejected).
• Operators — arithmetic + - * / % (with string + concatenation), comparison < <= > >=, equality == != (deep, number-cross-type), logical && || (short-circuit), unary - / !, and the right-associative conditional c ? t : f — all with HCL's precedence.
• for-expressions — tuple [for x in xs : e if cond] and object {for k, v in m : k => v if cond}, the optional key/index var, the if filter, and the … grouping mode for objects.
• Function calls — f(args…) with the trailing … spread, the try / can special forms (lazy, error-suppressing), and a pure standard-library subset (below).
• Diagnostics — Diagnostic / Diagnostics with 1-based line:col positions, mirroring HCL's error reporting.

CGO-free, dependency-free, 100% test coverage, gofmt + go vet clean, and green across the six 64-bit Go targets (amd64, arm64, riscv64, loong64, ppc64le, s390x) on Linux, macOS, and Windows.

Install

go get github.com/go-ruby-hcl2/hcl2

Usage

package main

import (
	"fmt"

	"github.com/go-ruby-hcl2/hcl2"
)

func main() {
	ctx := hcl2.NewContext()
	ctx.Variables["env"] = "prod"

	m, _ := hcl2.Eval(`
name    = "web-${env}"
count   = 3
ports   = [for p in [80, 443] : p]
service "api" {
  port = 9090
}
`, ctx)

	// Eval returns an insertion-ordered *hcl2.Map (a Ruby Hash).
	name, _ := m.Get("name")
	fmt.Println(name) // web-prod

	svc, _ := m.Get("service")
	api, _ := svc.(*hcl2.Map).Get("api")
	port, _ := api.(*hcl2.Map).Get("port")
	fmt.Println(port) // 9090

	// Parse alone yields a lazy *Body for per-attribute decoding.
	body, _ := hcl2.Parse(`region = upper("eu")`)
	region, _, _ := body.Attr("region", nil)
	fmt.Println(region) // EU
}

Ruby value model

Eval returns an any drawn from a small, fixed set of Go types, so a host can map its own object graph to and from this package:

HCL has a single number type; this package narrows an integral number to int64 and a fractional one to float64, so the host materialises Integer vs Float naturally — exactly as it does for the JSON and TOML backends.

API

// Parse parses a document into a lazy *Body (no evaluation).
func Parse(src string) (*Body, error)

// Eval parses and evaluates a document against ctx, returning a Ruby Hash.
func Eval(src string, ctx *Context) (*Map, error)

// EvalExpr parses and evaluates a single expression string.
func EvalExpr(src string, ctx *Context) (Value, error)

// EvalFile reads and evaluates a file.
func EvalFile(path string, ctx *Context) (*Map, error)

// Body.Attr evaluates one attribute lazily against ctx.
func (b *Body) Attr(name string, ctx *Context) (Value, bool, error)

type Context struct {
	Variables map[string]any
	Functions map[string]Func
}
func NewContext() *Context

type Func func(args []any) (any, error)

type Map struct { /* insertion-ordered Hash */ }
func NewMap() *Map
func (m *Map) Set(key string, val any)
func (m *Map) Get(key string) (any, bool)
func (m *Map) Pairs() []Pair
func (m *Map) Len() int

type Diagnostic  struct{ Summary string; Pos Pos } // mirrors hcl.Diagnostic
type Diagnostics []*Diagnostic                      // mirrors hcl.Diagnostics
type Pos         struct{ Line, Col, Offset int }

Standard-library functions

A pure (side-effect-free) subset of the Terraform/HCL function library ships built-in; a host shadows any of them via Context.Functions:

length, upper, lower, trimspace, min, max, abs, floor, ceil, concat, join, split, keys, values, lookup, contains, coalesce, reverse, format, tostring, tonumber, tobool, jsonencode, jsondecode, plus the try / can special forms.

format supports the %s %d %f %g %t %q %v %% verbs. keys / values return their results in sorted-key order (matching HCL). jsonencode emits objects in insertion order; jsondecode round-trips into the value model above.

Grammar coverage

The deferred items are deliberately scoped out of this milestone (matching the C reference's roadmap) and are documented here rather than faked; the native syntax above is complete.

Tests & coverage

There is no Ruby HCL gem oracle, so the whole suite is deterministic, interpreter-free spec-vector + golden tests (parse-tree and eval-result assertions, plus an error/diagnostic corpus). They alone hold coverage at 100%, so every CI lane — Linux/macOS/Windows and the qemu cross-arch lanes — passes the gate identically.

COVERPKG=$(go list ./... | paste -sd, -)
go test -race -coverpkg="$COVERPKG" -coverprofile=cover.out ./...
go tool cover -func=cover.out | tail -1   # 100.0%

License

BSD-3-Clause — see LICENSE. Copyright the go-ruby-hcl2/hcl2 authors.

WebAssembly

Being pure Go (CGO=0), this library also compiles to WebAssembly — both GOOS=js GOARCH=wasm (browser / Node.js) and GOOS=wasip1 GOARCH=wasm (WASI). CI builds both targets on every push, alongside the six 64-bit native/qemu arches.

GOOS=js     GOARCH=wasm go build ./...   # browser / Node
GOOS=wasip1 GOARCH=wasm go build ./...   # WASI (wasmtime, wasmer, wasmedge, …)
