rexml

rexml — go-ruby-rexml

A pure-Go (no cgo) reimplementation of the core of Ruby's REXML XML library — the tree model, the parser, the serialisers (the compact default formatter and Formatters::Pretty), and a widely-used subset of XPath — matching MRI 4.0.5's rexml 3.4.4 behaviour without any Ruby runtime.

It is built from scratch rather than wrapping encoding/xml: REXML's API, whitespace handling and round-trip semantics differ. REXML keeps text and attribute values in their raw, still-escaped form, defaults to single-quoted attributes, sorts attributes by local name in the compact formatter (but keeps source order in Pretty), self-closes empty elements, and preserves comments / CDATA / processing instructions verbatim — so ParseDocument(xml).ToString() reproduces what REXML::Document.new(xml).to_s emits, byte-for-byte.

It is the REXML backend for go-embedded-ruby, but is a standalone, reusable module with no dependency on the Ruby runtime — a sibling of go-ruby-yaml (Psych), go-ruby-regexp (Onigmo) and go-ruby-erb (ERB).

Features

Faithful port of REXML's DOM + parse + serialise + XPath, validated against the ruby binary on every supported platform:

• Parse — ParseDocument builds a tree of Document / Element / Attribute / Text / Comment / CData / Instruction (PI) / DocType / XMLDecl, preserving raw text, entities, the XML declaration and the DOCTYPE (including a bracketed internal subset). Malformed input returns a *ParseError with a byte offset, mirroring REXML::ParseException.
• DOM — Element{Prefix, Name, Attributes, Children, …} with Add / AddElement / AddAttribute / AddText / SetText, Elements(path), EachElement, ChildElements, Text / GetText / Texts, ElementAt(n) (1-based), FirstElement, QName / ExpandedName / Prefix / NamespaceURI, Root / RootNode. Attributes is an ordered map.
• Serialise — (*Document).ToString (compact, REXML's to_s), Write(WriteOptions), and the Pretty formatter Pretty(indent) / PrettyString — matching REXML's exact output: single-quoted attributes, local-name attribute ordering (compact) vs source order (Pretty), entity escaping (& < > in text, & < > " ' for programmatic values, literal ' escaped to ' inside the single-quoted form), numeric-reference and CDATA / comment / PI round-trip, and self-closing empty elements.
• XPath subset — XPathFirst / XPathEach / XPathMatch over the common subset (see the boundary below).

CGO-free, dependency-free, 100% test coverage, gofmt + go vet clean, and green across the six 64-bit Go targets (amd64, arm64, riscv64, loong64, ppc64le, s390x).

Install

go get github.com/go-ruby-rexml/rexml

Usage

package main

import (
	"fmt"

	"github.com/go-ruby-rexml/rexml"
)

func main() {
	d, _ := rexml.ParseDocument(`<config><server name="web" port="8080"/></config>`)

	fmt.Println(d.ToString())
	// <config><server name='web' port='8080'/></config>   (attrs sorted, single-quoted)

	fmt.Println(d.Pretty(2))
	// <config>
	//   <server name='web' port='8080'/>
	// </config>

	srv := rexml.XPathFirst(d, "//server").(*rexml.Element)
	name, _ := srv.Attr("name")
	fmt.Println(name) // web

	// Build a tree programmatically.
	doc := rexml.NewDocument()
	root := doc.AddElement("root")
	root.AddElement("item").AddText("hello & <world>")
	fmt.Println(doc.ToString())
	// <root><item>hello &amp; &lt;world&gt;</item></root>
}

Node model

ParseDocument returns a *Document whose Children hold the top-level nodes (optional *XMLDecl, *DocType, comments / PIs, and the single root *Element). Every node implements the unexported Node interface; the concrete types a host binds are:

XPath subset boundary

XPathMatch / XPathFirst / XPathEach implement the widely-used subset REXML's XPath covers:

Supported — absolute (/a/b/c) and descendant (//tag, a//b) paths; the wildcard *; the child and descendant axes; attribute steps @attr and @*; the text() node test; and predicates [n] (1-based per-parent position, matching REXML's //a[1] selecting the first a within each parent), [@attr] (existence) and [@attr='v'] / [@attr="v"] (value, compared against the decoded attribute value). A relative path applied to a *Document resolves from the root element, like REXML.

Out of scope (documented boundary) — axes other than child / descendant (no ancestor, following-sibling, parent, ..); functions beyond text() (no count(), position(), last(), name(), contains(), …); arithmetic; and compound boolean predicates (and / or). An unrecognised predicate leaves the node set unchanged.

Tests & coverage

The suite pairs deterministic, ruby-free tests (which alone hold coverage at 100%, so the qemu cross-arch and Windows lanes pass the gate) with a differential MRI oracle: a wide XML corpus is parsed and re-serialised here and by the system ruby (REXML::Document.new(xml).to_s, Formatters::Pretty, REXML::XPath.match), and the bytes are compared exactly. The oracle feeds XML through stdin and $stdout.binmode / $stdin.binmode so Windows text-mode never pollutes the bytes; it is gated to Ruby ≥ 4.0 and skips itself where ruby is absent.

COVERPKG=$(go list ./... | paste -sd, -)
go test -race -coverpkg="$COVERPKG" -coverprofile=cover.out ./...
go tool cover -func=cover.out | tail -1   # 100.0%

License

BSD-3-Clause — see LICENSE. Copyright the go-ruby-rexml/rexml authors.

WebAssembly

Being pure Go (CGO=0), this library also compiles to WebAssembly — both GOOS=js GOARCH=wasm (browser / Node.js) and GOOS=wasip1 GOARCH=wasm (WASI). CI builds both targets on every push, alongside the six 64-bit native/qemu arches.

GOOS=js     GOARCH=wasm go build ./...   # browser / Node
GOOS=wasip1 GOARCH=wasm go build ./...   # WASI (wasmtime, wasmer, wasmedge, …)
